| Parameter | Value |
|---|---|
| Rated Voltage (Un) | 11 kV |
| Reactive Power (Qn) | 300 kvar |
| Capacitance (Cn) | 7.89 μF |
| Rated Frequency (Fn) | 50 / 60 Hz |
| Configuration | Three-phase integrated |
| Standards | GB/T 11024 · IEC 60871 |
| № | TYPE | Un (kV) | Qn (kVAR) | Fn (Hz) | In (A) | Cn (μF) | L (mm) | W (mm) | H (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | BAM11-300-3W | 11 | 300 | 50(60) | 15.8 | 7.89 | 560 | 150 | 380 | Enquire |
Talk to our engineers about custom specifications or to request a datasheet.
